HD DOOR Door Control Cards

Hedefsan HD DOOR Door Control Cards

+7 Segment Display

+Not need Limited Shalter

+Door open and close counter

• HD DOOR controller ensures full hold of the motor with its 4 region motor control and high-resolution doubie line encoder input hardware.

• Basic parameters (door opening-closing speed,obstruction pressure signal type and demo mode) can be adjusted via built-in 7segrnent displays and buttons.

• A nudging function is included which allows closing the door slowly with an audible alarm in case the photocell remains interrupted longer than the alllowed duration

• It has the features for auto-learning of door travel limits without open-close limit switches,

• In case of power failure, it can get the power from 2 pcs 12V batteries or 24VDC external supply, The emergency supply type can be selected easily via a jumper on board.

• It provides many functions and parameters for manufacturing companies that enabie application flexibility, like motor reduction ratio motor revolution motor sheave circumference and skate open zone

• It provides users with parameter setting with speed units in cm/s and travel distance units in centimeters,

• It proviides setting adjustment for door opentrflg-closing pressure as well as obstruction pressure according to needs,

• It provides a counter for the information of opening-closing times,

• It allows swift and comfortable motion of doors with its software that provides S softening in travel ramps and which has the algorithm that does not require limift switches
